Steel Hinged Doors

Overview



STEEL HINGED DOORS

 (THE FIRE DOOR)

Fire doors are designed to contain and prevent the spread of a fire for a specified period of time, this means that all fire doors must hold a certification that guarantees the minimum amount of protection the door will provide in the event of a fire.

Features



Fire Rated Specification Features

Door Leaf – Manufactured from 1.6mm or 2mm zintec steel, double skinned with interlocking seams reinforced vertically with interlocking channels and horizontally with tubes to prevent twisting. Spaces are filled with dense Rockwool. Door leaf thickness is 45mm.

Door Frame – Manufactured from 1.6mm zintec formed to a single or double rebated profile in welded or knock down form, reinforced and fitted with fixing plates. Depth of frame can vary to suit brick, block and steelwork or to span a cavity. Standard sizes are 100mm x 38mm for single rebated frames and 145mm x 38mm for double rebated frames.

Hinges – All hinges are stainless steel ball bearing butt hinges. The number and size depend upon the size and weight of the particular door leaf.

Cills – A number of different types of cills are available depending upon the application.

Ironmongery – The most common types of ironmongery for personnel doors are lever handles on one/both sides of the door leaf, a sashlock and latch complete with euro profile key cylinder on one/both sides of the door leaf or an internal thumb-turn in lieu of the key cylinder. A non-locking latch can be provided instead of the sashlock. Hydraulic door-closers are generally provided as standard.

Fire Rating – Single door sets, with or without glazing, have a 6 hour rating. Double door sets have a 6 hour rating without glazing and a 4 hour rating with glazing.

Finish – Doors are finished in etch primer ready for immediate painting. A powder coated finish is optional and can be provided at extra cost.

Budget Specification Features

Door Leaf – Manufactured from 1mm zinc plated sheet steel with 25mm honeycomb cell resin impregnated paper core. Anti-jemmy dog-bolts are fitted on hinge side of leaf. Door leaf thickness is 45mm.

Door Frame – Manufactured from 2mm zinc plated sheet steel with 12mm high stainless steel threshold and 3no. adjustable fixing points each side of the frame. Supplied ready assembled with the door leaf mounted within the door frame.

Hinges – 4no. stainless steel butt hinges are screwed to the door and frame.

Cills – A number of different types of cills are available depending upon the application.

Ironmongery: Personnel Doors – Stainless steel 19mm lever handles on both sides of the door leaf together with a sash lock and latch complete with euro profile key cylinder on both sides of the door leaf.

Ironmongery: Fire Exit Doors – Panic bar complete with two point locking, top and bottom. An external locking knob set can be provided at extra cost.

Fire Rating – Single door sets, with or without glazing, have a 6 hour rating. Double door sets have a 6 hour rating without glazing and a 4 hour rating with glazing.

Finish – Doors are finished in grey polyester paint suitable to accept either powder coating or site painting.
